La technologie de synthétiseur légendaire du Waldorf Quantum – désormais dotée de nouvelles fonctionnalités.    Quantum MK2 a été mis à niveau avec un clavier aftertouch polyphonique de 61 touches de Fatar, un stockage d'échantillonnage augmenté à 59 Go, une conception mécanique et un affichage améliorés.
Le nouveau firmware 3.0 permet jusqu'à 16 numériques ou toute combinaison utilisant le filtre 8 analogiques avec 8 numériques supplémentaires

Specifications

• Hybrid Digital/Analog Polyphonic Synthesizer


• 61 Keys high-quality Fatar TP/8SK keyboard, channel aftertouch


• 8 voices with analog filter, up to 16 voices with digital filters


• Dual timbral: split or layered mode with separate stereo audio outputs


• 3 stereo digital oscillators each capable of five synthesis algorithms


• Wavetable: Waldorf style with latest additions from Nave including speech synthesis, wavetable generation from audio and new features


• Waveform: Waveform with up to 8 simultaneous waves per Oscillator in detuned or chordal mode with hard-sync, warp & PWM as well as tunable noise


• Particle: Sampler in traditional and granular mode using multi-samples or live input


• Resonator: Exciter using multi-sampling plus filter bank sound model.


• New Kernel synthesis with possibilities from classic 6 operator FM to innovative audio rate wavetable modulations


• Two analogue lowpass filters per voice each in 24 or 12 dB configuration using innovative link modes, or alternatively two digital multi-mode filters


• Digital former: Additional digital algorithms per voice like comb filter, high-pass, band-pass & notch filters (Nave, Largo or PPG models), bit-crusher, drive and more


• Flexible routing system for order of filters & digital former and individual oscillator routings


• 6 LFOs in poly and global mode with extensive parameter set


• 6 loopable envelopes


• Komplex: multistage LFO/envelope modulator


• Extensive modulation matrix with 40 slots and easy via-controller assignments


• Intuitive modulation assignment via panel elements and control LEDs


• Master effect rack of 5 slots for each timbre choosing from FX like phaser, flanger, chorus, reverb, drive, eq and more.


• Compressor for main output


• Step sequencer with step recording, parameter automation and scale-based pitch quantization


• Microtonal pitch configurations capable of importing Skala scl files


• Capable of polyphonic aftertouch via internal keybed or external MIDI inputs


• Chord and latch buttons


• Unisono mode


• Module-based preset system for effects, oscillators, step-sequenzer and Komplex modulator


• Single-function potentiometer and encoder controls for intuitive editing


• Visualisation and deeper sound editing via context-sensitive high-resolution capacitive multi-touch display


• Spectrum Analyzer and Oscilloscope at various processing stages


• Up to 10,000 sound patch capacity organized by banks, attributes, author and patch number.


• Favourites lists for quick recall of sound patches like for set-lists etc.


• Pre-loaded with wide variety of patches by acclaimed sound designers


• MIDI output of local keyboard, wheels and assignable panel elements


• Automation of sound parameters from MIDI inputs via MIDI CC learn function


• Recording of samples from audio inputs or self-recording of audio outputs


• 4 GB*) internal Flash memory for presets and wavetables, 59GB internal sample storage


• Pre-loaded with approx. 2 GB sample data


• On board audio file editor


• Export & import of presets, sample & wavetable via SD card or USB drive


• Import of Nave presets and selected legacy FM .syx files


• Mod wheel can be assigned to any parameter which can be modulated in the matrix or via quick assign


• Pitch wheel can be assigned to each oscillator individually

Sampling capabilities Each of the 3 Oscillators of a single timbre can be used in one of three modes using samples:

• Stereo Multi-Sampler with looping and reverse playback


• Granular Sampler with extensive parameter set


• Resonator model using sampler as exciter


• Samples are organized using key and velocity maps, selections rules like round robin, random etc., and individual pitch, gain and pan settings.


• Samples are stored in internal Flash memory of 59GB capacity pre-filled with 2GB specially made for Quantum factory samples.


• New samples can be recorded from external stereo audio inputs, or from self-recording Quantums own engine.


• Samples can also be imported an stored to internal Flash via SD card or USB drive using WAV and AIFF file format (44.1kHz sample rate).


• The Quantum allows for a huge range of sample-based sound design capabilities from classical synths sounds to uncharted territories.


• It’s worth noting that the sample use in the Quantum is always within a synthesizer’s sonic context, and it is not meant to work as a “bread and butter” sample keyboard to play back like traditional sampling instruments nor third party libraries.

Huge range of arpeggiator parameters:

• 7 Algorithms to choose from like up, down, random etc.


• Octave range


• 7 Sort Orders


• 3 Velocity Modes


• Gate length


• Swing


• BPM


• Beat Division


• Rhythmic patterns


• Reset Modes


• Keyboard Latch chordal and non-chordal

If that’s not enough, individual patterns can be created in the step sequencer including transpositions and scale quantisations.

Connections:

• 2x stereo audio outputs for main and aux timbres


• Stereo audio input for sample recording and real-time processing


• High-Quality 24bit A/D and D/A converters


• Headphone out with separate level adjustment


• Sustain pedal input


• Control pedal connector also capable of CV input (0-5V sensitivity)


• USB host type A connector for interfacing MIDI controller or USB drives for sample/preset exchange and software updates


• USB device type B connector for interfacing computer or other class-compliant MIDI USB hosts like iOS devices


• SD Card for sample/preset exchange and software updates


• DIN MIDI In, Out & Thru


• Integrated power supply unit

Weight: 17.8 kg

Dimensions: 1.006 x 401 x 131 mm
